From highway stretches to hidden forest campsites, lighting isn’t just a luxury—it’s a safety necessity. At IRONMAN 4×4, we believe that the right lighting transforms your entire off-road experience. Whether you're navigating dark roads, tight switchbacks, or setting up camp, this guide— based on one of our hands-on workshops—covers everything you need to know.



Understanding Off‑Road Lighting Needs

Off-road lighting can be simplified into three key categories: driving lights, trail lights, and camp lights. The first issue we want to resolve should always be focused around the greatest affect. For example, if you primarily do a lot of night highway driving then focus on driving light solutions first. If you do a lot of night trail driving then focus on trail light solutions, and so on.

Let's break down each of the three categories to provide better understanding of what they can provide, and shed some light on which will be the best solution for you.

Driving Lights – Extend Your Highway Vision

IRONMAN 4X4 Lights



Driving lights are defined as any high power auxiliary light that you would use while driving on the highway. So we are thinking of lighting solutions to enhance and extend our area of illumination further down the road when we are traveling at faster highway speeds. Also lights that help broaden our view of the fog lines of the road, especially in adverse weather conditions, like a fog light.

Even with high beams, you'll often out‑drive your headlights at highway speeds... you need more reaction time than stock lights can offer.

Driving lights typically come in three beam flavors, either spot beam, combo beam, or flood beam. These names describe the type of beam pattern that the light is made with and often look like this:

Light Beam Pattern



Spot beam is a very narrow highly focused light beam pattern designed to send as much light directly down range as possible. The lens of the light fixture is focused to illuminate way down the highway so you are able to see the whole road much farther than you could with your factory headlights. This allows you to see obstacles or animals in the road much sooner than you would with even your factory high beams on, providing you much more time to react and safely slow the vehicle down to maneuver around the obstacle

Combo beam is a spot beam that also has a wider outer light cast:

Light Beam Pattern

Typically the Combo beam light reflector is a spot beam in the center of the lens and a flood beam around the outer edge of the lens. This provides you the benefit of a spot beam with more shoulder of the road illumination. My favorite light setup is having a spot beam mounted on the driver side with a combo beam on the passenger side. The thought here is the spot beam is closest to the center line of the highway so it will shoot down the middle of the road and get me that long distance illumination. The combo beam is closer to the shoulder of the road so it will help fill in the sides further down illuminating potential animals that may be eager to play a game of frogger.

Spot and combo beam driving lights are mounted at headlight level on your aftermarket front bumper. This is where IRONMAN 4x4 Scope Driving Lights come in: available in 5", 7", and 9" sizes, with TIR optics and hooded reflectors for optimized beam projection and minimal light scatter. The larger the light the more light output. Wiring them into your high-beam switch or with a aux switch panel enables rapid control and keeps oncoming drivers safe. But do consider power draw and installed space restrictions to help with size choice.

Tundra Lights



Flood beam is a wide scattered beam of light designed to illuminate a wide swath of area at the sacrifice of distance:

Cube Light Beam Pattern



Think of fog lights. These are lights that are mounted down low on the front bumper and face outward more towards the fog lines of both sides of the road. Fog lights illuminate the painted fog lines and the immediate shoulder of the road, helping you keep it between the lines at night. Think of using smaller cube lights for fog lights. If you need enhanced visibility in foggy or dusty conditions, then upgrade your fog lights to an amber lens or an amber LED. Amber light scatters less off of dust particles and enhances definition.

Trail Lights – Navigate Every Turn

Sunsent Canyon Trial Lighting



On tight twisty trails, stock headlights don’t light the corners and obstacles behind you. Trail lights are defined as any light that you would use while driving on the trail. Typically, you are traveling at a much slower speed than highway driving and making many more sharp turns, that’s where ditch lights shine, and reversing, that's where back up lights stand out.

Cube lights from IRONMAN 4x4 are perfect for this. With flood or spot beam patterns and optional amber or clear lenses, they mount easily on A-pillars or bumpers, light up the areas that your stock lights miss.

Ditch lights should be mounted on the a-pillar and aimed outward to the sides. These will fill the gap between the fog light and the b-pillar, guiding your out-the-side-window vision on hairpin turns. Don’t aim them straight forward as the light will cast glare on your hood ruining your night vision… unless you are trying to get more followers on the gram then all logic is flushed down the toilet.

Cube Light Closeup



If you have to reverse down a tight trail, having backup lights aimed straight back and out to the sides will help light up those ditches and rocks so you can see where you are going. Think of this setup as a mini set of driving lights and fog lights, just mounted on your rear bumper.

For both ditch lights and back up lights use flood cubes for width, spot cubes for range, or mix them for maximum excitement.

Another trail light to consider is a light bar up on your roof rack facing forward for wide immediate visibility. Light bars typically are a combo beam light pattern and are great for lighting up the world around you on tight trails. Try to set it back enough on your roof rack to limit the amount of light spill on your hood, unless, you know, that gram thing.

Bronco with Front Bumper Light and LED Light Bar On



Lastly, I would add here rock lights. These are lights mounted in wheel wells, under sliders, and under bumpers to illuminate the ground around you so you can see tire placement and any immediate obstacle. These can also double as camp lights when walking around your vehicle so a good double use case here.

Camp Lights – Your Campsite Companion

Campsite with LED Area Light



Sometimes it happens and you get into camp at dark. You need to setup camp and make a meal and being able to see what you are doing is considered helpful. Camp lights are defined as any lights that are used when the vehicle is parked and you need to do work in and around the vehicle. So this may look like scene lighting when working off the back or side of the vehicle. Or it may be interior lighting for convenience and cooking.

Camp lights are typically lower light output since they are for immediate working areas and you don’t want to blind people camping next to you. Place your camp lights in areas where you do the most work, add a dimmer switch to adjust the vibe as the kids say. I like to have lights under my vehicle illuminating the ground so as I walk around to get to things I have great footing visibility. I have some small side lights off of the roof rack for setting up camp or cooking under the awning, plus some additional lights in the back of the vehicle for getting in and out of the fridge and drawers.

Remember that camp lights are used when your vehicle is off so run these off of an auxiliary battery and switch system that is powered separately to avoid draining down your main engine start battery to avoid being stranded with a dead battery in the morning.

Smart Wiring & Setup Tips

Light Switches



Line up your wiring plan so lights are user‑friendly: wire driving lights like Scope lights or cubes into your high-beam switch or an auxiliary switch panel (e.g. SwitchPro, S-Tech, Aux Beam systems) for tactile, intuitive control without looking away from the road.

Trails lights can also be on your aux switch panel for convenience. With camp lights I like to have the switches in the areas that I am working in, think like you house. You have a switch in the garage to get to your tools, and a switch in your kitchen to cook. Same should be on your vehicle.

Use IRONMAN 4x4 pre-wired harness kits—they include relay, fuse blocks, Deutsch connectors, and harnesses. Protect wiring with split or mesh loom and zip tie all the things down to keep wires secure, apply dielectric grease to plugs to prevent corrosion and bad contacts, and label circuits clearly so you can troubleshoot easily in the field.

Choosing the Right Setup

  • If you do a lot of night driving on highways, start with Scope spot or combo driving lights.
  • If you need to navigate tight trails in darkness, use cube lights as ditch lights.
  • If you camp frequently at night, consider scene lights, cube lights, or camp lights powered separately so you don’t drain your main battery.
  • Use amber or yellow light covers to reduce glare in fog, for dust, and you can always swap them quickly when conditions demand it.

Final Takeaways for Off‑Road Lighting

Bronco Lighting



  • Don’t feel pressure to install everything at once; start with your most-used scenario.
  • Combine Scope driving lights for distance, cube pods for periphery and backup, and camp lights for camp ambience.
  • High-quality installation is key—safe wiring, durable connectors, and clear labeling.
  • Product accessories like snap-on covers and modular switch panels give you flexibility as needs evolve.

By blending workshop insights with IRONMAN 4x4’s product range, you’ll be ready to light your path—or light up the night—all on your terms.

Miller explaining lighting



FAQs: IRONMAN 4x4 Lighting Demystified

Q: Are amber covers better for fog than yellow?
A: Both reduce glare, but selective amber tends to cut through dense fog or snow more effectively, thanks to wavelength optimization.

Q: Can I pair cube lights with Scope beams?
A: Absolutely. A combo of long-range Scope lights and flood-pattern cube pods offers full forward and side fog line illumination.

Q: How do I avoid lighting glare on my hood?
A: Position driving lights low and near your headlights, aim cube lights outward, and avoid uncontrolled roof-mounted fixtures that spill light onto the hood.

Q: What’s the benefit of combo beams?
A: Combo beams combine the reach of spot with the width of flood—ideal for mixed pace driving where both sides and distance matter.

Q: Do lights need a separate battery for camp use?
A: It’s recommended. Using a secondary battery prevents draining your main vehicle battery when lighting for extended campsite usage.
